Description
Compatible with Audio Developments / SQN / Sound Devices / Cooper / Mixy
Hirose RM15TRD-10S, mating cable connector: Hirose RM15TPD-10P
| Pin | SX-M32 | SX-ES64/ES84 |
|---|---|---|
| 1 | Out Left + | Main Out 1 + |
| 2 | Out Left – | Main Out 1 – |
| 3 | Out Right + | Main Out 2 + |
| 4 | Out Right – | Main Out 2 – |
| 5 | Return Left + | Return Right + (connected to EXT on Monitor selector) |
| 6 | Return Left Gnd | Return Right – or Gnd if unbalanced |
| 7 | Return Right + | Return Left + (connected to EXT on Monitor selector) |
| 8 | Return Right Gnd | Return Left – or Gnd if unbalanced |
| 9 | Gnd | Gnd |
| 10 | Gnd | Gnd |
